Transistors - FETs, MOSFETs - Single

Records 6294
Page  203/210
Part Number
Manufacturer
Description
Package
Stock
Quantity
Package
Series
FET Type
Technology
Drain to Source Voltage (Vdss)
Current - Continuous Drain (Id) @ 25°C
Drive Voltage (Max Rds On, Min Rds On)
Vgs(th) (Max) @ Id
Gate Charge (Qg) (Max) @ Vgs
Input Capacitance (Ciss) (Max) @ Vds
Vgs (Max)
FET Feature
Power Dissipation (Max)
Rds On (Max) @ Id, Vgs
Operating Temperature
Mounting Type
Supplier Device Package
Package / Case
Infineon Technologies
MOSFET N-CH 150V DIRECTFET L8
Package: DirectFET? Isometric L8
Stock117,468
DirectFET? Isometric L8
HEXFET?
N-Channel
MOSFET (Metal Oxide)
150V
375A (Tc)
10V
5V @ 250µA
150nC @ 10V
6660pF @ 25V
±20V
-
3.3W (Ta), 125W (Tc)
11 mOhm @ 40A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
DIRECTFET L8
DirectFET? Isometric L8
Infineon Technologies
MOSFET N-CH 100V 100A TO220-3
Package: TO-220-3
Stock77,052
TO-220-3
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
100V
100A (Tc)
6V, 10V
3.5V @ 150µA
117nC @ 10V
8410pF @ 50V
±20V
-
214W (Tc)
4.5 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Through Hole
PG-TO-220-3
TO-220-3
Infineon Technologies
MOSFET N-CH 75V DIRECTFET L8
Package: DirectFET? Isometric L8
Stock32,148
DirectFET? Isometric L8
HEXFET?
N-Channel
MOSFET (Metal Oxide)
75V
26A (Ta), 375A (Tc)
10V
4V @ 250µA
300nC @ 10V
12222pF @ 25V
±20V
-
3.3W (Ta), 125W (Tc)
2.3 mOhm @ 96A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
DIRECTFET L8
DirectFET? Isometric L8
Infineon Technologies
MOSFET N-CH 100V DIRECTFET L8
Package: DirectFET? Isometric L8
Stock32,664
DirectFET? Isometric L8
HEXFET?
N-Channel
MOSFET (Metal Oxide)
100V
375A (Tc)
10V
4V @ 250µA
300nC @ 10V
11560pF @ 25V
±20V
-
3.3W (Ta), 125W (Tc)
3.5 mOhm @ 74A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
DIRECTFET L8
DirectFET? Isometric L8
Infineon Technologies
MOSFET N-CH 100V 180A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock140,400
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
100V
180A (Tc)
10V
4V @ 250µA
215nC @ 10V
9575pF @ 50V
±20V
-
375W (Tc)
4.7 mOhm @ 106A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 55V 104A TO-220AB
Package: TO-220-3
Stock15,504
TO-220-3
HEXFET?
N-Channel
MOSFET (Metal Oxide)
55V
104A (Tc)
4V, 10V
2V @ 250µA
130nC @ 5V
5000pF @ 25V
±16V
-
200W (Tc)
8 mOhm @ 54A, 10V
-55°C ~ 175°C (TJ)
Through Hole
TO-220AB
TO-220-3
Infineon Technologies
MOSFET N-CH 800V 17A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock1,362,132
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
CoolMOS?
N-Channel
MOSFET (Metal Oxide)
800V
17A (Tc)
10V
3.9V @ 1mA
177nC @ 10V
2300pF @ 100V
±20V
-
227W (Tc)
290 mOhm @ 11A, 10V
-55°C ~ 150°C (TJ)
Surface Mount
PG-TO263-3-2
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 80V 120A TO263-3
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock44,784
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
80V
120A (Tc)
6V, 10V
3.5V @ 270µA
206nC @ 10V
14200pF @ 40V
±20V
-
300W (Tc)
2.5 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
PG-TO263-2
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 60V 120A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock19,512
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
60V
120A (Tc)
10V
4V @ 150µA
120nC @ 10V
4520pF @ 50V
±20V
-
230W (Tc)
4.2 mOhm @ 75A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 40V 300A 8HSOF
Package: 8-PowerSFN
Stock33,840
8-PowerSFN
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
40V
300A (Tc)
10V
4V @ 230µA
287nC @ 10V
22945pF @ 25V
±20V
-
429W (Tc)
0.77 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
H-PSOF-8-1
8-PowerSFN
Infineon Technologies
MOSFET N-CH 55V 110A TO-247AC
Package: TO-247-3
Stock161,508
TO-247-3
HEXFET?
N-Channel
MOSFET (Metal Oxide)
55V
110A (Tc)
10V
4V @ 250µA
170nC @ 10V
4000pF @ 25V
±20V
-
200W (Tc)
8 mOhm @ 59A, 10V
-55°C ~ 175°C (TJ)
Through Hole
TO-247AC
TO-247-3
Infineon Technologies
MOSFET N-CH 900V 15A TO-263
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock13,392
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
CoolMOS?
N-Channel
MOSFET (Metal Oxide)
900V
15A (Tc)
10V
3.5V @ 1mA
11nC @ 10V
2400pF @ 100V
±20V
-
208W (Tc)
340 mOhm @ 9.2A, 10V
-55°C ~ 150°C (TJ)
Surface Mount
PG-TO263
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 40V 46A DIRECTFETL8
Package: DirectFET? Isometric L8
Stock35,850
DirectFET? Isometric L8
-
N-Channel
MOSFET (Metal Oxide)
40V
46A (Ta), 270A (Tc)
10V
4V @ 250µA
330nC @ 10V
11880pF @ 25V
±20V
-
3.8W (Ta), 125W (Tc)
1 mOhm @ 160A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
DIRECTFET L8
DirectFET? Isometric L8
Infineon Technologies
MOSFET N-CH 30V 300A 8HSOF
Package: 8-PowerSFN
Stock19,104
8-PowerSFN
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
30V
300A (Tc)
4.5V, 10V
2.2V @ 250µA
163nC @ 4.5V
24000pF @ 15V
±20V
-
3.8W (Ta), 300W (Tc)
0.4 mOhm @ 150A, 10V
-55°C ~ 150°C (TJ)
Surface Mount
PG-HSOF-8-1
8-PowerSFN
Infineon Technologies
MOSFET N-CH 60V 195A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock112,044
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
60V
195A (Tc)
4.5V, 10V
2.5V @ 250µA
140nC @ 4.5V
11210pF @ 50V
±16V
-
380W (Tc)
2.4 mOhm @ 165A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 60V 180A TO263-7
Package: TO-263-7, D2Pak (6 Leads + Tab)
Stock21,258
TO-263-7, D2Pak (6 Leads + Tab)
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
60V
180A (Tc)
4.5V, 10V
2.2V @ 196µA
166nC @ 4.5V
28000pF @ 30V
±20V
-
250W (Tc)
1.6 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
PG-TO263-7
TO-263-7, D2Pak (6 Leads + Tab)
Infineon Technologies
MOSFET N-CH 100V 180A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock444,540
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
100V
180A (Tc)
4.5V, 10V
2.5V @ 250µA
130nC @ 4.5V
11360pF @ 50V
±16V
-
370W (Tc)
4.3 mOhm @ 110A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 40V 240A D2PAK7
Package: TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Stock18,624
TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
40V
240A (Tc)
10V
4V @ 250µA
240nC @ 10V
9130pF @ 25V
±20V
-
380W (Tc)
1.25 mOhm @ 195A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK (7-Lead)
TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Infineon Technologies
MOSFET P-CH 55V 42A TO-262
Package: TO-262-3 Long Leads, I2Pak, TO-262AA
Stock3,600
TO-262-3 Long Leads, I2Pak, TO-262AA
HEXFET?
P-Channel
MOSFET (Metal Oxide)
55V
42A (Tc)
10V
4V @ 250µA
180nC @ 10V
3500pF @ 25V
±20V
-
170W (Tc)
20 mOhm @ 42A, 10V
-55°C ~ 150°C (TJ)
Through Hole
TO-262
TO-262-3 Long Leads, I2Pak, TO-262AA
Infineon Technologies
MOSFET P-CH 100V 38A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock985,248
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
HEXFET?
P-Channel
MOSFET (Metal Oxide)
100V
38A (Tc)
10V
4V @ 250µA
230nC @ 10V
2780pF @ 25V
±20V
-
3.1W (Ta), 170W (Tc)
60 mOhm @ 38A, 10V
-55°C ~ 150°C (TJ)
Surface Mount
D2PAK
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 40V 180A TO263-7
Package: TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Stock6,132
TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
40V
180A (Tc)
4.5V, 10V
2V @ 200µA
346nC @ 10V
29000pF @ 20V
±20V
-
250W (Tc)
1.1 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
PG-TO263-7-3
TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Infineon Technologies
MOSFET N-CH 60V 240A D2PAK-7
Package: TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Stock14,532
TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
60V
240A (Tc)
4.5V, 10V
2.5V @ 250µA
160nC @ 4.5V
11270pF @ 50V
±16V
-
380W (Tc)
1.9 mOhm @ 180A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK (7-Lead)
TO-263-7, D2Pak (6 Leads + Tab), TO-263CB
Infineon Technologies
MOSFET N-CH 150V 35A TO-220AB
Package: TO-220-3
Stock132,528
TO-220-3
HEXFET?
N-Channel
MOSFET (Metal Oxide)
150V
35A (Tc)
10V
5V @ 100µA
26nC @ 10V
1750pF @ 50V
±20V
-
144W (Tc)
39 mOhm @ 21A, 10V
-55°C ~ 175°C (TJ)
Through Hole
TO-220AB
TO-220-3
Infineon Technologies
MOSFET N-CH 55V 75A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock29,400
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
HEXFET?
N-Channel
MOSFET (Metal Oxide)
55V
75A (Tc)
10V
4V @ 250µA
290nC @ 10V
7960pF @ 25V
±20V
-
300W (Tc)
3.3 mOhm @ 75A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
D2PAK
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 100V 20A DIRECTFET
Package: DirectFET? Isometric L8
Stock30,240
DirectFET? Isometric L8
-
N-Channel
MOSFET (Metal Oxide)
100V
20A (Ta), 124A (Tc)
10V
4V @ 250µA
300nC @ 10V
11560pF @ 25V
±20V
-
3.3W (Ta), 125W (Tc)
3.5 mOhm @ 74A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
DIRECTFET L8
DirectFET? Isometric L8
Infineon Technologies
MOSFET N-CH 60V 120A TO263-3
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock13,206
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
60V
120A (Tc)
4.5V, 10V
2.2V @ 196µA
166nC @ 4.5V
28000pF @ 30V
±20V
-
250W (Tc)
1.9 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
PG-TO263-2
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET P-CH 100V 40A TO-220AB
Package: TO-220-3
Stock6,400
TO-220-3
HEXFET?
P-Channel
MOSFET (Metal Oxide)
100V
40A (Tc)
10V
4V @ 250µA
180nC @ 10V
2700pF @ 25V
±20V
-
200W (Tc)
60 mOhm @ 24A, 10V
-55°C ~ 175°C (TJ)
Through Hole
TO-220AB
TO-220-3
Infineon Technologies
MOSFET N-CH 40V 120A TO263-3
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock390,000
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
40V
120A (Tc)
4.5V, 10V
2V @ 200µA
346nC @ 10V
28000pF @ 25V
±20V
-
250W (Tc)
1.5 mOhm @ 100A, 10V
-55°C ~ 175°C (TJ)
Surface Mount
PG-TO263-2
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Infineon Technologies
MOSFET N-CH 100V 31A TO220FP
Package: TO-220-3 Full Pack
Stock5,600
TO-220-3 Full Pack
HEXFET?
N-Channel
MOSFET (Metal Oxide)
100V
31A (Tc)
4V, 10V
2V @ 250µA
140nC @ 5V
3700pF @ 25V
±16V
-
63W (Tc)
26 mOhm @ 16A, 10V
-55°C ~ 175°C (TJ)
Through Hole
TO-220AB Full-Pak
TO-220-3 Full Pack
Infineon Technologies
MOSFET N-CH 150V 87A TDSON-8
Package: 8-PowerTDFN
Stock41,664
8-PowerTDFN
OptiMOS?
N-Channel
MOSFET (Metal Oxide)
150V
87A (Tc)
8V, 10V
4.6V @ 107µA
40.7nC @ 10V
3230pF @ 75V
±20V
-
139W (Tc)
9.3 mOhm @ 44A, 10V
-55°C ~ 150°C (TJ)
Surface Mount
PG-TDSON-8
8-PowerTDFN
