Fixed Inductors

Records 2600
Page  86/87
Part Number
Manufacturer
Description
Package
Stock
Quantity
Package
Series
Type
Material - Core
Inductance
Tolerance
Current Rating
Current - Saturation
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Operating Temperature
Frequency - Test
Features
Mounting Type
Package / Case
Supplier Device Package
Size / Dimension
Height - Seated (Max)
Vishay Dale
FIXED IND 470NH 17.5A 4.2 MOHM
Package: Nonstandard
Stock236,712
Nonstandard
IHLP-2525CZ-01
Molded
-
470nH
±20%
17.5A
26A
Shielded
4.2 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 820NH 13A 8 MOHM SMD
Package: Nonstandard
Stock263,400
Nonstandard
IHLP-2525CZ-01
Molded
-
820nH
±20%
13A
24A
Shielded
8 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 220NH 23A 2.8 MOHM SMD
Package: Nonstandard
Stock11,712
Nonstandard
IHLP-2525CZ-01
Molded
-
220nH
±20%
23A
40A
Shielded
2.8 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 680NH 15.5A 5.5 MOHM
Package: Nonstandard
Stock269,844
Nonstandard
IHLP-2525CZ-01
Molded
-
680nH
±20%
15.5A
25A
Shielded
5.5 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 1.5UH 9A 15 MOHM SMD
Package: Nonstandard
Stock1,663,812
Nonstandard
IHLP-2525CZ-01
Molded
-
1.5µH
±20%
9A
18A
Shielded
15 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 3.3UH 6A 30 MOHM SMD
Package: Nonstandard
Stock214,776
Nonstandard
IHLP-2525CZ-01
Molded
-
3.3µH
±20%
6A
13.5A
Shielded
30 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 1UH 11A 10 MOHM SMD
Package: Nonstandard
Stock171,060
Nonstandard
IHLP-2525CZ-01
Molded
-
1µH
±20%
11A
22A
Shielded
10 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 2.2UH 8A 20 MOHM SMD
Package: Nonstandard
Stock899,448
Nonstandard
IHLP-2525CZ-01
Molded
-
2.2µH
±20%
8A
14A
Shielded
20 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 4.7UH 5.5A 40 MOHM SMD
Package: Nonstandard
Stock259,116
Nonstandard
IHLP-2525CZ-01
Molded
-
4.7µH
±20%
5.5A
10A
Shielded
40 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.270" L x 0.255" W (6.86mm x 6.47mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 470NH 12.2A 7.04 MOHM
Package: Nonstandard
Stock29,658
Nonstandard
IHLP-2020CZ-01
Molded
-
470nH
±20%
12.2A
16A
Shielded
7.04 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 10UH 2.75A 131.9 MOHM
Package: Nonstandard
Stock30,930
Nonstandard
IHLP-2020CZ-11
Molded
-
10µH
±20%
2.75A
2.25A
Shielded
131.9 mOhm Max
-
17MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 4.7UH 3.2A 81.3 MOHM
Package: Nonstandard
Stock144,000
Nonstandard
IHLP-2020BZ-11
Molded
-
4.7µH
±20%
3.2A
3A
Shielded
81.3 mOhm Max
-
27MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 6.8UH 2.4A 150 MOHM
Package: Nonstandard
Stock35,976
Nonstandard
IHLP-2020BZ-01
Molded
-
6.8µH
±20%
2.4A
4.3A
Shielded
150 mOhm Max
-
21MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 4.7UH 3.5A 77.5 MOHM
Package: Nonstandard
Stock18,840
Nonstandard
IHLP-2020CZ-01
Molded
-
4.7µH
±20%
3.5A
8.2A
Shielded
77.5 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 3.3UH 3.3A 85.5 MOHM
Package: Nonstandard
Stock49,284
Nonstandard
IHLP-2020BZ-01
Molded
-
3.3µH
±20%
3.3A
8.5A
Shielded
85.5 mOhm Max
-
30MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 15UH 1.9A 265 MOHM SMD
Package: Nonstandard
Stock63,750
Nonstandard
IHLP-2020CZ-01
Molded
-
15µH
±20%
1.9A
2.5A
Shielded
265 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 1UH 9.2A 13.7 MOHM SMD
Package: Nonstandard
Stock77,370
Nonstandard
IHLP-2020CZ-01
Molded
-
1µH
±20%
9.2A
12A
Shielded
13.7 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 22UH 1.9A 270 MOHM SMD
Package: Nonstandard
Stock70,464
Nonstandard
IHLP-2020CZ-11
Molded
-
22µH
±20%
1.9A
1.7A
Shielded
270 mOhm Max
-
10MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 5.6UH 4.25A 70.6 MOHM
Package: Nonstandard
Stock95,964
Nonstandard
IHLP-2020CZ-11
Molded
-
5.6µH
±20%
4.25A
3.5A
Shielded
70.6 mOhm Max
-
23MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 2.2UH 5.8A 29.2 MOHM
Package: Nonstandard
Stock77,142
Nonstandard
IHLP-2020CZ-01
Molded
-
2.2µH
±20%
5.8A
10A
Shielded
29.2 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 100NH 17A 3.9 MOHM SMD
Package: Nonstandard
Stock106,032
Nonstandard
IHLP-2020BZ-01
Molded
-
100nH
±20%
17A
45A
Shielded
3.9 mOhm Max
-
239MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 3.3UH 5A 54.7 MOHM SMD
Package: Nonstandard
Stock115,416
Nonstandard
IHLP-2020CZ-01
Molded
-
3.3µH
±20%
5A
8.5A
Shielded
54.7 mOhm Max
-
-
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 1UH 7.5A 18.1 MOHM SMD
Package: Nonstandard
Stock86,466
Nonstandard
IHLP-2020BZ-11
Molded
-
1µH
±20%
7.5A
7A
Shielded
18.1 mOhm Max
-
66MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 1UH 10A 11 MOHM SMD
Package: Nonstandard
Stock113,802
Nonstandard
IHLP-2020CZ-11
Molded
-
1µH
±20%
10A
6.5A
Shielded
11 mOhm Max
-
66MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.118" (3.00mm)
Vishay Dale
FIXED IND 10UH 2.3A 199 MOHM SMD
Package: Nonstandard
Stock114,276
Nonstandard
IHLP-2020BZ-01
Molded
-
10µH
±20%
2.3A
4A
Shielded
199 mOhm Max
-
20MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 470NH 11.5A 9.4 MOHM
Package: Nonstandard
Stock12,288
Nonstandard
IHLP-2020BZ-01
Molded
-
470nH
±20%
11.5A
21A
Shielded
9.4 mOhm Max
-
98MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 1UH 7A 20 MOHM SMD
Package: Nonstandard
Stock2,000
Nonstandard
IHLP-2020BZ-01
Molded
-
1µH
±20%
7A
16A
Shielded
20 mOhm Max
-
62MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.216" L x 0.204" W (5.49mm x 5.18mm)
0.079" (2.00mm)
Vishay Dale
FIXED IND 1MH 66MA 16 OHM SMD
Package: 1812 (4532 Metric)
Stock22,098
1812 (4532 Metric)
ISC-1812
Wirewound
Ferrite
1mH
±10%
66mA
-
Shielded
16 Ohm Max
30 @ 252kHz
2MHz
-
-55°C ~ 125°C
252kHz
-
Surface Mount
1812 (4532 Metric)
1812
0.177" L x 0.126" W (4.50mm x 3.20mm)
0.134" (3.40mm)
Vishay Dale
FIXED IND 15UH 4.9A 65.3 MOHM
Package: Nonstandard
Stock60,678
Nonstandard
IHLP-3232DZ-11
Molded
-
15µH
±20%
4.9A
3.7A
Shielded
65.3 mOhm Max
-
10.3MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.340" L x 0.322" W (8.64mm x 8.18mm)
0.157" (4.00mm)
Vishay Dale
FIXED IND 33UH 3.2A 144 MOHM SMD
Package: Nonstandard
Stock263,082
Nonstandard
IHLP-3232DZ-11
Molded
-
33µH
±20%
3.2A
3.2A
Shielded
144 mOhm Max
-
6.7MHz
-
-55°C ~ 125°C
100kHz
-
Surface Mount
Nonstandard
-
0.340" L x 0.322" W (8.64mm x 8.18mm)
0.157" (4.00mm)
