Chip Resistor - Surface Mount

Records 75685
Page  2482/2523
Part Number
Manufacturer
Description
Package
Stock
Quantity
Package
Series
Resistance
Tolerance
Power (Watts)
Composition
Features
Temperature Coefficient
Operating Temperature
Package / Case
Supplier Device Package
Size / Dimension
Height - Seated (Max)
Number of Terminations
Failure Rate
Vishay Dale
RES SMD 50 OHM 2% 11W 1206
Package: 1206 (3216 Metric)
Stock27,096
1206 (3216 Metric)
RCP
50 Ohms
±2%
11W
Thick Film
Moisture Resistant
±150ppm/°C
-55°C ~ 155°C
1206 (3216 Metric)
1206
0.122" L x 0.060" W (3.10mm x 1.52mm)
0.025" (0.64mm)
2
-
Vishay Dale
RES SMD 50 OHM 1% 2W 4527
Package: 4527 J-Lead
Stock13,542
4527 J-Lead
WSC
50 Ohms
±1%
2W
Wirewound
Pulse Withstanding
±20ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.177" (4.49mm)
2
-
Vishay Dale
RES SMD 1 OHM 1% 2W 4527
Package: 4527 J-Lead
Stock22,500
4527 J-Lead
WSC
1 Ohms
±1%
2W
Wirewound
Pulse Withstanding
±50ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.177" (4.49mm)
2
-
Vishay Dale
RES SMD 0.0003 OHM 1% 3W 3921
Package: 3921
Stock75,054
3921
WSL
3 µOhms
±1%
3W
Metal Element
Current Sense, Moisture Resistant, Pulse Withstanding
±175ppm/°C
-65°C ~ 170°C
3921
3921
0.394" L x 0.205" W (10.00mm x 5.20mm)
0.020" (0.50mm)
2
-
Vishay Dale
RES SMD 0.003 OHM 1% 3W 4527
Package: 4527 J-Lead
Stock66,912
4527 J-Lead
WSR
3 mOhms
±1%
3W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±450ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.100" (2.54mm)
2
-
Vishay Dale
RES SMD 0.02 OHM 1% 1W 2512
Package: 2512 (6432 Metric)
Stock16,536
2512 (6432 Metric)
WSLS
20 mOhms
±1%
1W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.01 OHM 1% 1W 2512
Package: 2512 (6432 Metric)
Stock48,228
2512 (6432 Metric)
WSLS
10 mOhms
±1%
1W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.005 OHM 1% 3W 4527
Package: 4527 J-Lead
Stock12,348
4527 J-Lead
WSR
5 mOhms
±1%
3W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±110ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.100" (2.54mm)
2
-
Vishay Dale
RES SMD 0.009 OHM 1% 1W 2512
Package: 2512 (6432 Metric)
Stock126,444
2512 (6432 Metric)
WSL
9 mOhms
±1%
1W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 2 OHM 1% 1/2W 2012
Package: 2012 J-Lead
Stock15,822
2012 J-Lead
WSC
2 Ohms
±1%
0.5W, 1/2W
Wirewound
Pulse Withstanding
±50ppm/°C
-65°C ~ 175°C
2012 J-Lead
2012
0.200" L x 0.125" W (5.08mm x 3.18mm)
0.111" (2.82mm)
2
-
Vishay Dale
RES SMD 49.9K OHM 1% 0.15W 0705
Package: 0805 (2012 Metric)
Stock21,492
0805 (2012 Metric)
Military, MIL-PRF-55342, RM0705
49.9 kOhms
±1%
0.15W
Thick Film
Military
±100ppm/°C
-55°C ~ 150°C
0805 (2012 Metric)
0705
0.080" L x 0.050" W (2.03mm x 1.27mm)
0.033" (0.84mm)
2
R (0.01%)
Vishay Dale
RES SMD 1K OHM 1% 0.15W 0705
Package: 0805 (2012 Metric)
Stock22,992
0805 (2012 Metric)
Military, MIL-PRF-55342, RM0705
1 kOhms
±1%
0.15W
Thick Film
Military
±100ppm/°C
-55°C ~ 150°C
0805 (2012 Metric)
0705
0.080" L x 0.050" W (2.03mm x 1.27mm)
0.033" (0.84mm)
2
R (0.01%)
Vishay Dale
RES SMD 0.004 OHM 1% 3W 3921
Package: 3921
Stock22,464
3921
WSL
4 mOhms
±1%
3W
Metal Element
Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
3921
3921
0.394" L x 0.205" W (10.00mm x 5.20mm)
0.020" (0.50mm)
2
-
Vishay Dale
RES SMD 0.002 OHM 1% 3W 3921
Package: 3921
Stock2,952
3921
WSL
2 mOhms
±1%
3W
Metal Element
Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
3921
3921
0.394" L x 0.205" W (10.00mm x 5.20mm)
0.020" (0.50mm)
2
-
Vishay Dale
RES SMD 0.003 OHM 1% 3W 3921
Package: 3921
Stock86,988
3921
WSL
3 mOhms
±1%
3W
Metal Element
Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
3921
3921
0.394" L x 0.205" W (10.00mm x 5.20mm)
0.020" (0.50mm)
2
-
Vishay Dale
RES SMD 0.05 OHM 1% 2W 2816
Package: 2816
Stock24,000
2816
WSL
50 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2816
2816
0.280" L x 0.165" W (7.10mm x 4.20mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.033 OHM 1% 2W 2512
Package: 2512 (6432 Metric)
Stock20,922
2512 (6432 Metric)
WSL-HP
33 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.022 OHM 1% 2W 2512
Package: 2512 (6432 Metric)
Stock77,370
2512 (6432 Metric)
WSL-HP
22 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.018 OHM 1% 2W 2512
Package: 2512 (6432 Metric)
Stock95,892
2512 (6432 Metric)
WSL-HP
18 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.01 OHM 1% 2W 2512
Package: 2512 (6432 Metric)
Stock96,264
2512 (6432 Metric)
WSL-HP
10 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 170°C
2512 (6432 Metric)
2512
0.250" L x 0.125" W (6.35mm x 3.18mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.003 OHM 1% 1/4W 1206
Package: 1206 (3216 Metric)
Stock85,938
1206 (3216 Metric)
WSL
3 mOhms
±1%
0.25W, 1/4W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±150ppm/°C
-65°C ~ 170°C
1206 (3216 Metric)
1206
0.126" L x 0.063" W (3.20mm x 1.60mm)
0.035" (0.89mm)
2
-
Vishay Dale
RES SMD 0.0 OHM JUMP 0.15W 0705
Package: 0805 (2012 Metric)
Stock23,088
0805 (2012 Metric)
Military, MIL-PRF-32159, RCZ0705
0 Ohms
Jumper
0.15W
Thick Film
Military
-
-55°C ~ 150°C
0805 (2012 Metric)
0705
0.080" L x 0.050" W (2.03mm x 1.27mm)
0.033" (0.84mm)
2
M (1%)
Vishay Dale
RES SMD 0.015 OHM 1% 3W 4527
Package: 4527 J-Lead
Stock144,000
4527 J-Lead
WSR
15 mOhms
±1%
3W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.100" (2.54mm)
2
-
Vishay Dale
RES SMD 470K OHM 0.1% 1/4W 1206
Package: 1206 (3216 Metric)
Stock17,994
1206 (3216 Metric)
TNPV
470 kOhms
±0.1%
0.25W, 1/4W
Thin Film
High Voltage, Anti-Sulfur, Moisture Resistant
±25ppm/°C
-55°C ~ 125°C
1206 (3216 Metric)
1206
0.126" L x 0.063" W (3.20mm x 1.60mm)
0.026" (0.65mm)
2
-
Vishay Dale
RES SMD 330K OHM 0.1% 1/4W 1206
Package: 1206 (3216 Metric)
Stock19,638
1206 (3216 Metric)
TNPV
330 kOhms
±0.1%
0.25W, 1/4W
Thin Film
High Voltage, Anti-Sulfur, Moisture Resistant
±25ppm/°C
-55°C ~ 125°C
1206 (3216 Metric)
1206
0.126" L x 0.063" W (3.20mm x 1.60mm)
0.026" (0.65mm)
2
-
Vishay Dale
RES SMD 0.04 OHM 1% 2W 4527
Package: 4527 J-Lead
Stock141,720
4527 J-Lead
WSR
40 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.100" (2.54mm)
2
-
Vishay Dale
RES SMD 0.03 OHM 1% 2W 4527
Package: 4527 J-Lead
Stock14,238
4527 J-Lead
WSR
30 mOhms
±1%
2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±75ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.100" (2.54mm)
2
-
Vishay Dale
RES SMD 10 OHM 1% 2W 4527
Package: 4527 J-Lead
Stock14,400
4527 J-Lead
WSC
10 Ohms
±1%
2W
Wirewound
Pulse Withstanding
±20ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.177" (4.49mm)
2
-
Vishay Dale
RES SMD 5 OHM 1% 2W 4527
Package: 4527 J-Lead
Stock57,258
4527 J-Lead
WSC
5 Ohms
±1%
2W
Wirewound
Pulse Withstanding
±50ppm/°C
-65°C ~ 275°C
4527 J-Lead
4527
0.455" L x 0.275" W (11.56mm x 6.98mm)
0.177" (4.49mm)
2
-
Vishay Dale
RES SMD 0.002 OHM 1% 1/2W 2010
Package: 2010 (5025 Metric)
Stock74,304
2010 (5025 Metric)
WSL
2 mOhms
±1%
0.5W, 1/2W
Metal Element
Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
±275ppm/°C
-65°C ~ 170°C
2010 (5025 Metric)
2010
0.200" L x 0.100" W (5.08mm x 2.54mm)
0.035" (0.89mm)
2
-
