Diodes - Rectifiers - Single

Records 769
Page  3/26
Part Number
Manufacturer
Description
Package
Stock
Quantity
Package
Series
Diode Type
Voltage - DC Reverse (Vr) (Max)
Current - Average Rectified (Io)
Voltage - Forward (Vf) (Max) @ If
Speed
Reverse Recovery Time (trr)
Current - Reverse Leakage @ Vr
Capacitance @ Vr, F
Mounting Type
Package / Case
Supplier Device Package
Operating Temperature - Junction
STMicroelectronics
DIODE SCHOTTKY 60V 1A DO41
Package: DO-204AL, DO-41, Axial
Stock39,780
DO-204AL, DO-41, Axial
-
Schottky
60V
1A
570mV @ 1A
Fast Recovery =< 500ns, > 200mA (Io)
-
50µA @ 60V
-
Through Hole
DO-204AL, DO-41, Axial
DO-41
150°C (Max)
STMicroelectronics
DIODE SCHOTTKY 40V 1A SOD123
Package: SOD-123
Stock142,200
SOD-123
-
Schottky
40V
1A (DC)
550mV @ 1A
Fast Recovery =< 500ns, > 200mA (Io)
-
40µA @ 400V
-
Surface Mount
SOD-123
SOD-123
-40°C ~ 150°C
STMicroelectronics
DIODE GEN PURP 400V 30A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock18,612
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
400V
30A
1.45V @ 30A
Fast Recovery =< 500ns, > 200mA (Io)
100ns
15µA @ 400V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
-40°C ~ 175°C
STMicroelectronics
DIODE GEN PURP 1KV 12A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock6,688
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
1000V
12A
2V @ 12A
Fast Recovery =< 500ns, > 200mA (Io)
90ns
10µA @ 1000V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
175°C (Max)
STMicroelectronics
DIODE SCHOTTKY 60V 1A SMA
Package: DO-214AC, SMA
Stock142,800
DO-214AC, SMA
-
Schottky
60V
1A
670mV @ 1A
Fast Recovery =< 500ns, > 200mA (Io)
-
4µA @ 60V
-
Surface Mount
DO-214AC, SMA
SMA (DO-214AC)
-40°C ~ 150°C
STMicroelectronics
DIODE SCHOTTKY 80V 500MA MELF
Package: DO-213AB, MELF
Stock21,024
DO-213AB, MELF
-
Schottky
80V
500mA (DC)
420mV @ 100mA
Fast Recovery =< 500ns, > 200mA (Io)
-
200µA @ 80V
120pF @ 0V, 1MHz
Surface Mount
DO-213AB, MELF
MELF
-65°C ~ 125°C
STMicroelectronics
DIODE SCHOTTKY 45V 10A POWERFLAT
Package: 8-PowerTDFN
Stock19,200
8-PowerTDFN
-
Schottky
45V
10A
590mV @ 10A
Fast Recovery =< 500ns, > 200mA (Io)
-
200µA @ 45V
-
Surface Mount
8-PowerTDFN
PowerFlat? (3.3x3.3)
175°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 8A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock6,132
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
600V
8A
1.3V @ 8A
Fast Recovery =< 500ns, > 200mA (Io)
105ns
8µA @ 600V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
175°C (Max)
STMicroelectronics
DIODE SCHOTTKY 40V 3A SMB
Package: DO-214AA, SMB
Stock5,729,100
DO-214AA, SMB
-
Schottky
40V
3A
630mV @ 3A
Fast Recovery =< 500ns, > 200mA (Io)
-
20µA @ 40V
-
Surface Mount
DO-214AA, SMB
SMB
150°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 8A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock6,432
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
TURBOSWITCH?
Standard
600V
8A
1.75V @ 8A
Fast Recovery =< 500ns, > 200mA (Io)
52ns
100µA @ 600V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
150°C (Max)
STMicroelectronics
DIODE SCHOTTKY 30V 30A POWERFLAT
Package: 8-PowerVDFN
Stock5,856
8-PowerVDFN
-
Schottky
30V
30A
510mV @ 30A
Fast Recovery =< 500ns, > 200mA (Io)
-
750µA @ 30V
-
Surface Mount
8-PowerVDFN
PowerFlat? (5x6)
150°C (Max)
STMicroelectronics
DIODE GEN PURP 1KV 8A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock6,800
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
1000V
8A
2V @ 8A
Fast Recovery =< 500ns, > 200mA (Io)
85ns
5µA @ 1000V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
-40°C ~ 175°C
STMicroelectronics
DIODE SCHOTTKY 100V 1A SMB
Package: DO-214AA, SMB
Stock142,200
DO-214AA, SMB
Q Automotive
Schottky
100V
1A
770mV @ 1A
Fast Recovery =< 500ns, > 200mA (Io)
-
4µA @ 100V
-
Surface Mount
DO-214AA, SMB
SMB
-40°C ~ 175°C
STMicroelectronics
DIODE SCHOTTKY 45V 10A DPAK
Package: TO-252-3, DPak (2 Leads + Tab), SC-63
Stock38,400
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Schottky
45V
10A
630mV @ 10A
Fast Recovery =< 500ns, > 200mA (Io)
-
100µA @ 45V
-
Surface Mount
TO-252-3, DPak (2 Leads + Tab), SC-63
D-Pak
175°C (Max)
STMicroelectronics
DIODE GEN PURP 100V 20A IPAK
Package: TO-251-3 Short Leads, IPak, TO-251AA
Stock27,234
TO-251-3 Short Leads, IPak, TO-251AA
-
Standard
100V
20A
705mV @ 20A
Standard Recovery >500ns, > 200mA (Io)
-
140µA @ 100V
-
Through Hole
TO-251-3 Short Leads, IPak, TO-251AA
IPAK (TO-251)
175°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 30A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock22,704
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
600V
30A
1.55V @ 30A
Fast Recovery =< 500ns, > 200mA (Io)
90ns
25µA @ 600V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
-40°C ~ 175°C
STMicroelectronics
DIODE GEN PURP 400V 5A
Package: -
Stock184,764
-
*
-
-
-
-
-
-
-
-
-
-
-
-
STMicroelectronics
DIODE GEN PURP 200V 8A DPAK
Package: TO-252-3, DPak (2 Leads + Tab), SC-63
Stock2,656
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Standard
200V
8A
1.05V @ 8A
Fast Recovery =< 500ns, > 200mA (Io)
30ns
6µA @ 200V
-
Surface Mount
TO-252-3, DPak (2 Leads + Tab), SC-63
D-Pak
175°C (Max)
STMicroelectronics
DIODE GEN PURP 1KV 30A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock21,216
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
1000V
30A
2V @ 30A
Fast Recovery =< 500ns, > 200mA (Io)
100ns
15µA @ 1000V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
-40°C ~ 175°C
STMicroelectronics
DIODE GEN PURP 1.2KV 3A DPAK
Package: TO-252-3, DPak (2 Leads + Tab), SC-63
Stock7,872
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Standard
1200V
3A
2V @ 3A
Fast Recovery =< 500ns, > 200mA (Io)
115ns
10µA @ 1200V
-
Surface Mount
TO-252-3, DPak (2 Leads + Tab), SC-63
D-Pak
175°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 3A DPAK
Package: TO-252-3, DPak (2 Leads + Tab), SC-63
Stock7,232
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Standard
600V
3A
1.3V @ 3A
Fast Recovery =< 500ns, > 200mA (Io)
85ns
3µA @ 600V
-
Surface Mount
TO-252-3, DPak (2 Leads + Tab), SC-63
D-Pak
175°C (Max)
STMicroelectronics
DIODE GEN PURP 1.2KV 60A DO247
Package: DO-247-2 (Straight Leads)
Stock9,144
DO-247-2 (Straight Leads)
-
Standard
1200V
60A
2.25V @ 60A
Fast Recovery =< 500ns, > 200mA (Io)
125ns
30µA @ 1200V
-
Through Hole
DO-247-2 (Straight Leads)
DO-247
175°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 30A DOP3I
Package: DOP3I-2 Insulated (Straight Leads)
Stock32,022
DOP3I-2 Insulated (Straight Leads)
-
Standard
600V
30A
1.85V @ 30A
Fast Recovery =< 500ns, > 200mA (Io)
70ns
25µA @ 600V
-
Through Hole
DOP3I-2 Insulated (Straight Leads)
DOP3I
175°C (Max)
STMicroelectronics
DIODE GEN PURP 200V 8A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock156,264
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
-
Standard
200V
8A
1.05V @ 8A
Fast Recovery =< 500ns, > 200mA (Io)
30ns
6µA @ 200V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
175°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 2A DO41
Package: DO-204AL, DO-41, Axial
Stock311,178
DO-204AL, DO-41, Axial
-
Standard
600V
2A
1.7V @ 2A
Fast Recovery =< 500ns, > 200mA (Io)
50ns
2µA @ 600V
-
Through Hole
DO-204AL, DO-41, Axial
DO-41
-40°C ~ 175°C
STMicroelectronics
DIODE SCHOTTKY 150V 3A DO201AD
Package: DO-201AD, Axial
Stock106,704
DO-201AD, Axial
-
Schottky
150V
3A
820mV @ 3A
Fast Recovery =< 500ns, > 200mA (Io)
-
2µA @ 150V
-
Through Hole
DO-201AD, Axial
DO-201AD
175°C (Max)
STMicroelectronics
DIODE SCHOTTKY 100V 8A TO220AC
Package: TO-220-2
Stock64,200
TO-220-2
-
Schottky
100V
8A
710mV @ 8A
Fast Recovery =< 500ns, > 200mA (Io)
-
4.5µA @ 100V
-
Through Hole
TO-220-2
TO-220AC
175°C (Max)
STMicroelectronics
DIODE SCHOTTKY 60V 3A SMC
Package: DO-214AB, SMC
Stock1,297,092
DO-214AB, SMC
-
Schottky
60V
3A
700mV @ 3A
Fast Recovery =< 500ns, > 200mA (Io)
-
55µA @ 60V
-
Surface Mount
DO-214AB, SMC
SMC
150°C (Max)
STMicroelectronics
DIODE GEN PURP 600V 12A D2PAK
Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Stock2,512
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
TURBOSWITCH?
Standard
600V
12A
1.75V @ 12A
Fast Recovery =< 500ns, > 200mA (Io)
55ns
100µA @ 600V
-
Surface Mount
TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
D2PAK
150°C (Max)
STMicroelectronics
DIODE GEN PURP 200V 1.5A DO15
Package: DO-204AC, DO-15, Axial
Stock2,128
DO-204AC, DO-15, Axial
-
Standard
200V
1.5A
1V @ 1.5A
Fast Recovery =< 500ns, > 200mA (Io)
30ns
3µA @ 200V
-
Through Hole
DO-204AC, DO-15, Axial
DO-15
175°C (Max)
