Rectangular Connectors - Headers, Male Pins

Records 1121
Page  4/38
Part Number
Manufacturer
Description
Package
Stock
Quantity
Package
Series
Connector Type
Contact Type
Pitch - Mating
Style
Shrouding
Number of Positions
Number of Positions Loaded
Number of Rows
Row Spacing - Mating
Mounting Type
Termination
Fastening Type
Contact Length - Mating
Contact Length - Post
Overall Contact Length
Insulation Height
Contact Shape
Contact Finish - Mating
Contact Finish Thickness - Mating
Contact Finish - Post
Contact Material
Insulation Material
Features
Operating Temperature
Ingress Protection
Material Flammability Rating
Insulation Color
JST Sales America Inc.
CONN HEADER PA 9POS TOP SMT
Package: -
Stock5,850
-
PA
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
9
All
1
-
Surface Mount
Solder
Locking Ramp
-
-
-
0.350" (8.89mm)
Square
Tin
-
Tin
Copper Alloy
Polyamide (PA), Nylon
Board Guide, Pick and Place, Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER PH TOP 7POS 2MM
Package: -
Stock4,140
-
PH
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
7
All
1
-
Through Hole
Press-Fit, Solder
Detent Lock
0.130" (3.30mm)
0.134" (3.40mm)
0.333" (8.45mm)
0.236" (6.00mm)
Square
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER VH SIDE 3POS 3.96MM
Package: -
Stock5,526
-
VH
Header
Male Pin
0.156" (3.96mm)
Board to Cable/Wire
Shrouded - 1 Wall
3
All
1
-
Through Hole, Right Angle
Solder
Locking Ramp
0.303" (7.70mm)
0.142" (3.60mm)
-
0.335" (8.51mm)
Square
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER R/A SMD 26POS ZPD
Package: -
Stock2,358
-
ZPD
Header
Outer Shroud Contact
0.059" (1.50mm)
Board to Cable/Wire
Shrouded - 4 Wall
26
All
2
-
Surface Mount, Right Angle
Solder
Locking Ramp
-
-
-
0.309" (7.85mm)
Rectangular
Tin
-
Tin
Copper Alloy
Polyamide (PA), Nylon
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN ACH 1.2MM 2 POS
Package: -
Stock3,508
-
ACH
Header
Male Blade
0.047" (1.20mm)
Board to Cable/Wire
Shrouded - 3 Wall
2
All
1
-
Surface Mount, Right Angle
Solder
Detent Lock
-
-
-
0.055" (1.40mm)
Rectangular
Gold
-
-
Copper Alloy
Thermoplastic
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Black
JST Sales America Inc.
CONN HEADER PH TOP 11POS 2MM
Package: -
Stock22,044
-
PH
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
11
All
1
-
Through Hole
Press-Fit, Solder
Detent Lock
0.130" (3.30mm)
0.134" (3.40mm)
0.333" (8.45mm)
0.236" (6.00mm)
Square
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER XH TOP 2POS 2.5MM
Package: -
Stock254,316
-
XH
Header
Male Pin
0.098" (2.50mm)
Board to Cable/Wire
Shrouded - 4 Wall
2
All
1
-
Through Hole
Press-Fit, Solder
Detent Lock
-
0.134" (3.40mm)
-
0.276" (7.00mm)
Square
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6
Board Guide
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER VH TOP 9POS 3.96MM
Package: -
Stock2,718
-
VH
Header
Male Pin
0.156" (3.96mm)
Board to Cable/Wire
Shrouded - 1 Wall
9
All
1
-
Through Hole
Solder
Locking Ramp
0.303" (7.70mm)
0.146" (3.70mm)
0.575" (14.60mm)
0.370" (9.40mm)
Square
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER ZH SIDE 11POS 1.5MM
Package: -
Stock5,508
-
ZH
Header
Male Pin
0.059" (1.50mm)
Board to Cable/Wire
Shrouded - 4 Wall
11
All
1
-
Through Hole, Right Angle
Press-Fit, Solder
Detent Lock
0.094" (2.40mm)
0.106" (2.69mm)
-
0.146" (3.71mm)
Circular
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6, Glass Filled
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER ZH TOP 13POS 1.5MM
Package: -
Stock6,264
-
ZH
Header
Male Pin
0.059" (1.50mm)
Board to Cable/Wire
Shrouded - 4 Wall
13
All
1
-
Through Hole
Press-Fit, Solder
Detent Lock
0.094" (2.40mm)
0.106" (2.69mm)
0.256" (6.50mm)
0.177" (4.50mm)
Circular
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6, Glass Filled
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER EH TOP 6POS 2.5MM
Package: -
Stock8,460
-
EH
Header
Male Pin
0.098" (2.50mm)
Board to Cable/Wire
Shrouded - 3 Wall
6
All
1
-
Through Hole
Press-Fit, Solder
Friction Lock
0.130" (3.30mm)
0.126" (3.20mm)
-
0.236" (6.00mm)
Square
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER R/A 20POS NH
Package: -
Stock8,748
-
NH
Header
Male Pin
0.098" (2.50mm)
Board to Cable/Wire
Unshrouded
20
All
1
-
Through Hole, Right Angle
Solder
Friction Lock
0.217" (5.50mm)
0.118" (3.00mm)
-
0.220" (5.60mm)
Square
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER GH SIDE 11POS 1.25MM
Package: -
Stock20,406
-
GH
Header
Outer Shroud Contact
0.049" (1.25mm)
Board to Cable/Wire
Shrouded - 4 Wall
11
All
1
-
Surface Mount, Right Angle
Solder
Locking Ramp
-
-
-
0.167" (4.25mm)
Rectangular
Tin
-
Tin
Phosphor Bronze
Polyamide (PA9T), Nylon 9T
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER JWPF 4POS 2MM TIN
Package: -
Stock154,566
-
JWPF
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
4
All
1
-
Through Hole
Kinked Pin, Solder
Latch Holder
-
0.130" (3.30mm)
-
0.654" (16.61mm)
Square
Tin
-
Tin
Copper Alloy
Polybutylene Terephthalate (PBT), Glass Filled
Board Guide
-55°C ~ 85°C
Dust Tight, Waterproof
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER PA 5POS SIDE 2MM TIN
Package: -
Stock91,188
-
PA
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
5
All
1
-
Through Hole, Right Angle
Kinked Pin, Solder
Locking Ramp
0.126" (3.20mm)
0.134" (3.40mm)
-
0.256" (6.50mm)
Square
Tin
-
Tin
Copper Alloy
Polybutylene Terephthalate (PBT), Glass Filled
Board Guide
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER VERT 14POS RA
Package: -
Stock3,726
-
RA
Header
Male Pin
0.100" (2.54mm)
Board to Cable/Wire
Shrouded - 4 Wall
14
All
2
0.100" (2.54mm)
Through Hole
Solder
Latch Lock/Eject Hooks, Long
-
0.118" (3.00mm)
-
0.689" (17.50mm)
Square
Gold
Flash
-
Brass
Polybutylene Terephthalate (PBT), Glass Filled
Keying Slot
-55°C ~ 125°C
-
UL94 V-0
Black
JST Sales America Inc.
CONN HEADER VH TOP 2POS 3.96MM
Package: -
Stock3,418
-
VH
Header
Male Pin
0.156" (3.96mm)
Board to Cable/Wire
Shrouded - 1 Wall
2
All
1
-
Through Hole
Solder
Locking Ramp
0.303" (7.70mm)
0.146" (3.70mm)
0.575" (14.60mm)
0.370" (9.40mm)
Square
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER ZH SIDE 2POS 1.5MM
Package: -
Stock14,424
-
ZH
Header
Male Pin
0.059" (1.50mm)
Board to Cable/Wire
Shrouded - 4 Wall
2
All
1
-
Through Hole, Right Angle
Press-Fit, Solder
Detent Lock
0.094" (2.40mm)
0.106" (2.69mm)
-
0.146" (3.71mm)
Circular
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6, Glass Filled
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER PH TOP 8POS 2MM
Package: -
Stock137,088
-
PH
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
8
All
1
-
Through Hole
Press-Fit, Solder
Detent Lock
0.130" (3.30mm)
0.134" (3.40mm)
0.333" (8.45mm)
0.236" (6.00mm)
Square
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HDR SIDE ENTRY 14 POS 2MM
Package: -
Stock50,784
-
PUD
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
14
All
2
0.079" (2.00mm)
Through Hole, Right Angle
Solder
Latch Holder
-
0.118" (3.00mm)
-
0.335" (8.51mm)
Square
Tin
-
Tin
Copper Alloy
Polyamide (PA66), Nylon 6/6, Glass Filled
Board Guide
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER VERT 8POS NH
Package: -
Stock8,406
-
NH
Header
Male Pin
0.098" (2.50mm)
Board to Cable/Wire
Unshrouded
8
All
1
-
Through Hole
Solder
Friction Lock
0.236" (6.00mm)
0.134" (3.40mm)
0.496" (12.60mm)
0.126" (3.20mm)
Square
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER SH 2POS SIDE 1MM TIN
Package: -
Stock86,436
-
SR
Header
Male Pin
0.039" (1.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
2
All
1
-
Surface Mount, Right Angle
Solder
Push-Pull
-
-
-
0.114" (2.90mm)
Square
Tin
-
Tin
Copper Alloy
Polyamide (PA), Nylon
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER EH TOP 7POS 2.5MM
Package: -
Stock90,426
-
EH
Header
Male Pin
0.098" (2.50mm)
Board to Cable/Wire
Shrouded - 3 Wall
7
All
1
-
Through Hole
Press-Fit, Solder
Friction Lock
0.130" (3.30mm)
0.126" (3.20mm)
-
0.236" (6.00mm)
Square
Tin
-
Tin
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER PA 13POS SIDE SMT
Package: -
Stock8,784
-
PA
Header
Male Pin
0.079" (2.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
13
All
1
-
Surface Mount, Right Angle
Solder
Locking Ramp
-
-
-
0.224" (5.69mm)
Square
Tin
-
Tin
Copper Alloy
Polyamide (PA), Nylon
Pick and Place, Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER 4 POS R/A SMD 1.0MM
Package: -
Stock29,862
-
NSH
Header
Outer Shroud Contact
0.039" (1.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
4
All
1
-
Surface Mount, Right Angle
Solder
Latch Holder
-
-
-
0.173" (4.40mm)
-
Tin
-
Tin
Copper Alloy
Polyamide (PA), Nylon
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER EH SIDE 7POS 2.5MM
Package: -
Stock8,820
-
EH
Header
Male Pin
0.098" (2.50mm)
Board to Cable/Wire
Shrouded - 3 Wall
7
All
1
-
Through Hole, Right Angle
Press-Fit, Solder
Latch Lock
0.157" (4.00mm)
0.126" (3.20mm)
-
0.165" (4.20mm)
Square
Tin-Lead
-
Tin-Lead
Brass
Polyamide (PA66), Nylon 6/6
-
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER SHD 20POS TOP 1MM
Package: -
Stock5,346
-
SHD
Header
Male Pin
0.039" (1.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
20
All
2
-
Surface Mount
Solder
Push-Pull
-
-
-
0.167" (4.25mm)
Square
Gold
-
-
Phosphor Bronze
Polyamide (PA), Nylon, Glass Filled
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER GVH 3POS SMD
Package: -
Stock8,586
-
GVH
Header
Outer Shroud Contact
0.049" (1.25mm)
Board to Cable/Wire
Shrouded - 4 Wall
3
All
1
-
Surface Mount
Solder
Latch Holder
-
-
-
0.159" (4.05mm)
Rectangular
Tin
-
Tin
Phosphor Bronze
Polyamide (PA6T), Nylon 6T
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER SHD 40POS SIDE 1MM
Package: -
Stock23,790
-
SHD
Header
Male Pin
0.039" (1.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
40
All
2
-
Surface Mount, Right Angle
Solder
Push-Pull
-
-
-
0.217" (5.51mm)
Square
Gold
-
-
Phosphor Bronze
Polyamide (PA), Nylon, Glass Filled
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
JST Sales America Inc.
CONN HEADER SHLD 30POS SIDE 1MM
Package: -
Stock7,128
-
SHLD
Header
Non-Gendered
0.039" (1.00mm)
Board to Cable/Wire
Shrouded - 4 Wall
30
All
2
-
Surface Mount, Right Angle
Solder
Latch Holder
-
-
-
0.215" (5.45mm)
-
Gold
-
-
Phosphor Bronze
Polyamide (PA), Nylon
Solder Retention
-25°C ~ 85°C
-
UL94 V-0
Natural
