Part Number	Manufacturer	Description	Package	Stock	Package	Series	Connector Type	Contact Type	Pitch - Mating	Style	Shrouding	Number of Positions	Number of Positions Loaded	Number of Rows	Row Spacing - Mating	Mounting Type	Termination	Fastening Type	Contact Length - Mating	Contact Length - Post	Overall Contact Length	Insulation Height	Contact Shape	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Contact Material	Insulation Material	Features	Operating Temperature	Ingress Protection	Material Flammability Rating	Insulation Color
B14B-PNDZS-1 (T) (LF)(SN)	JST Sales America Inc.	CONN HEADR PND TOP 14POS 2MM PCB	Package: -	Stock46,860	-	PND	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	14	All	2	0.197" (5.00mm)	Through Hole	Solder	Locking Ramp	-	0.126" (3.20mm)	-	0.390" (9.91mm)	Square	Tin	-	Tin	Copper Alloy	Polyamide (PA66), Nylon 6/6, Glass Filled	Board Guide	-25°C ~ 85°C	-	UL94 V-0	Ivory
SM02B-SURS-TF	JST Sales America Inc.	CONN HEADER 2POS .8MM TIN SIDE E	Package: -	Stock130,224	-	SUR	Header	Outer Shroud Contact	0.031" (0.80mm)	Board to Cable/Wire	Shrouded - 4 Wall	2	All	1	-	Surface Mount, Right Angle	Solder	Push-Pull	-	-	-	0.069" (1.75mm)	Rectangular	Tin-Lead	-	Tin-Lead	Copper Alloy	Polyamide (PA), Nylon	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
S15B-JL-R(LF)(SN)	JST Sales America Inc.	CONN HDR 15POS 2.5MM T/H R/A	Package: -	Stock6,084	-	JL	Header	Male Pin	0.098" (2.50mm)	Board to Board	Shrouded - 4 Wall	15	All	1	-	Through Hole, Right Angle	Solder	Locking Ramp	-	0.134" (3.40mm)	-	0.240" (6.10mm)	Square	Tin	-	Tin	Brass	Polyamide (PA66), Nylon 6/6	Board Guide	-25°C ~ 85°C	-	UL94 V-0	Red
B2PS-VH	JST Sales America Inc.	CONN HEADER VH SIDE 2POS 3.96MM	Package: -	Stock7,146	-	VH	Header	Male Pin	0.156" (3.96mm)	Board to Cable/Wire	Shrouded - 1 Wall	2	All	1	-	Through Hole, Right Angle	Solder	Locking Ramp	0.303" (7.70mm)	0.142" (3.60mm)	-	0.335" (8.51mm)	Square	Tin-Lead	-	Tin-Lead	Brass	Polyamide (PA66), Nylon 6/6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
S10B-ZR-SM3A-TF	JST Sales America Inc.	CONN HEADER ZH SIDE 10POS 1.5MM	Package: -	Stock4,338	-	ZH	Header	Male Pin	0.059" (1.50mm)	Board to Cable/Wire	Shrouded - 4 Wall	10	All	1	-	Surface Mount, Right Angle	Solder	Detent Lock	-	-	-	0.146" (3.71mm)	Circular	Tin-Lead	-	Tin-Lead	Brass	Polyamide (PA46), Nylon 4/6, Glass Filled	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
B16B-PHDSS	JST Sales America Inc.	CONN HEADER PHD TOP 16POS 2MM	Package: -	Stock5,940	-	PHD	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	16	All	2	0.079" (2.00mm)	Through Hole	Solder	Detent Lock	0.114" (2.90mm)	0.118" (3.00mm)	0.291" (7.40mm)	0.256" (6.50mm)	Square	Tin-Lead	-	Tin-Lead	Copper Alloy	Polyamide (PA), Nylon, Glass Filled	-	-25°C ~ 85°C	-	UL94 V-0	Natural
S7B-ZR	JST Sales America Inc.	CONN HEADER ZH SIDE 7POS 1.5MM	Package: -	Stock8,298	-	ZH	Header	Male Pin	0.059" (1.50mm)	Board to Cable/Wire	Shrouded - 4 Wall	7	All	1	-	Through Hole, Right Angle	Press-Fit, Solder	Detent Lock	0.094" (2.40mm)	0.106" (2.69mm)	-	0.146" (3.71mm)	Circular	Tin-Lead	-	Tin-Lead	Brass	Polyamide (PA66), Nylon 6/6, Glass Filled	-	-25°C ~ 85°C	-	UL94 V-0	Natural
B9P-VH(LF)(SN)	JST Sales America Inc.	CONN HEADER VH TOP 9POS 3.96MM	Package: -	Stock6,966	-	VH	Header	Male Pin	0.156" (3.96mm)	Board to Cable/Wire	Shrouded - 1 Wall	9	All	1	-	Through Hole	Solder	Locking Ramp	0.303" (7.70mm)	0.146" (3.70mm)	0.575" (14.60mm)	0.370" (9.40mm)	Square	Tin	-	Tin	Brass	Polyamide (PA66), Nylon 6/6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
SM10B-SRSS-TB(LF)(SN)	JST Sales America Inc.	CONN HEADR SH 10POS SIDE 1MM TIN	Package: -	Stock74,664	-	SR	Header	Male Pin	0.039" (1.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	10	All	1	-	Surface Mount, Right Angle	Solder	Push-Pull	-	-	-	0.114" (2.90mm)	Square	Tin	-	Tin	Copper Alloy	Polyamide (PA), Nylon	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
BM10B-GHS-TBT(LF)(SN)(N)	JST Sales America Inc.	CONN HEADER GH TOP 10POS 1.25MM	Package: -	Stock119,028	-	GH	Header	Outer Shroud Contact	0.049" (1.25mm)	Board to Cable/Wire	Shrouded - 4 Wall	10	All	1	-	Surface Mount	Solder	Locking Ramp	-	-	-	0.159" (4.05mm)	Rectangular	Tin	-	Tin	Phosphor Bronze	Polyamide (PA9T), Nylon 9T	Pick and Place, Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
BM30B-GHDS-G-TF(LF)(SN)	JST Sales America Inc.	CONN HEADER 30POS GHD VERT SMD	Package: -	Stock6,588	-	GHD	Header	Outer Shroud Contact	0.049" (1.25mm)	Board to Cable/Wire	Shrouded - 4 Wall	30	All	2	-	Surface Mount	Solder	Locking Ramp	-	-	-	0.197" (5.00mm)	-	Gold	-	-	Phosphor Bronze	Polyamide (PA9T), Nylon 9T	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
B20B-PADSS-1(LF)(SN)	JST Sales America Inc.	CONN HEADER 20POS 2MM TIN	Package: -	Stock6,174	-	PAD	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	20	All	2	0.079" (2.00mm)	Through Hole	Solder	Locking Ramp	-	0.134" (3.40mm)	-	0.402" (10.20mm)	Square	Tin	-	Tin	Copper Alloy	Polyamide (PA66), Nylon 6/6, Glass Filled	Board Guide	-25°C ~ 85°C	-	UL94 V-0	Natural
B10B-PH-K-S	JST Sales America Inc.	CONN HEADER PH TOP 10POS 2MM	Package: -	Stock2,322	-	PH	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	10	All	1	-	Through Hole	Press-Fit, Solder	Detent Lock	0.130" (3.30mm)	0.134" (3.40mm)	0.333" (8.45mm)	0.236" (6.00mm)	Square	Tin-Lead	-	Tin-Lead	Brass	Polyamide (PA66), Nylon 6/6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
BM30B-SRDS-A-G-TF	JST Sales America Inc.	CONN HEADER SHD 30POS TOP W/BOSS	Package: -	Stock8,568	-	SHD	Header	Male Pin	0.039" (1.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	30	All	2	-	Surface Mount	Solder	Push-Pull	-	-	-	0.167" (4.25mm)	Square	Gold	-	-	Phosphor Bronze	Polyamide (PA), Nylon, Glass Filled	Board Guide, Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
B9B-ZR	JST Sales America Inc.	CONN HEADER ZH TOP 9POS 1.5MM	Package: -	Stock2,448	-	ZH	Header	Male Pin	0.059" (1.50mm)	Board to Cable/Wire	Shrouded - 4 Wall	9	All	1	-	Through Hole	Press-Fit, Solder	Detent Lock	0.094" (2.40mm)	0.106" (2.69mm)	0.256" (6.50mm)	0.177" (4.50mm)	Circular	Tin-Lead	-	Tin-Lead	Brass	Polyamide (PA66), Nylon 6/6, Glass Filled	-	-25°C ~ 85°C	-	UL94 V-0	Natural
BE8P-SHF-1AA(LF)(SN)	JST Sales America Inc.	CONN HDR BOTTOM ENTRY 8POS NH	Package: -	Stock2,898	-	NH	Header, Bottom Entry	Male Pin	0.098" (2.50mm)	Board to Cable/Wire	Unshrouded	8	All	1	-	Through Hole	Solder	Friction Lock	0.236" (6.00mm)	0.130" (3.30mm)	-	0.394" (10.00mm)	Square	Tin	-	Tin	Brass	Polyamide (PA6), Nylon 6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
BM14B-SRSS-TB	JST Sales America Inc.	CONN HEADER SH 14POS TOP 1MM TIN	Package: -	Stock4,572	-	SR	Header	Male Pin	0.039" (1.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	14	All	1	-	Surface Mount	Solder	Push-Pull	-	-	-	0.167" (4.25mm)	Square	Tin-Lead	-	Tin-Lead	Copper Alloy	Polyamide (PA), Nylon	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
B11B-XASK-1	JST Sales America Inc.	CONN HEADER XA 11POS 2.5MM TIN	Package: -	Stock6,696	-	XA	Header	Male Pin	0.098" (2.50mm)	Board to Cable/Wire	Shrouded - 4 Wall	11	All	1	-	Through Hole	Press-Fit, Solder	Locking Ramp	-	0.134" (3.40mm)	-	0.346" (8.80mm)	Circular	Tin-Lead	-	Tin-Lead	Copper Alloy	Polyamide (PA66), Nylon 6/6, Glass Filled	-	-25°C ~ 85°C	-	UL94 V-0	Natural
S4B-PH-SM3-TB	JST Sales America Inc.	CONN HEADER PH SIDE 4POS 2MM SMD	Package: -	Stock2,466	-	PH	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	4	All	1	-	Surface Mount, Right Angle	Solder	Detent Lock	0.130" (3.30mm)	-	-	0.217" (5.51mm)	Square	Tin-Lead	-	Tin-Lead	Brass	Polyamide (PA46), Nylon 4/6	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
BE2P-SHF-1AA(LF)(SN)	JST Sales America Inc.	CONN HDR BOTTOM ENTRY 2POS NH	Package: -	Stock5,742	-	NH	Header, Bottom Entry	Male Pin	0.098" (2.50mm)	Board to Cable/Wire	Unshrouded	2	All	1	-	Through Hole	Solder	Friction Lock	0.236" (6.00mm)	0.130" (3.30mm)	-	0.394" (10.00mm)	Square	Tin	-	Tin	Brass	Polyamide (PA6), Nylon 6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
BM13B-SRSS-TB	JST Sales America Inc.	CONN HEADER SH 13POS TOP 1MM TIN	Package: -	Stock7,398	-	SR	Header	Male Pin	0.039" (1.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	13	All	1	-	Surface Mount	Solder	Push-Pull	-	-	-	0.167" (4.25mm)	Square	Tin-Lead	-	Tin-Lead	Copper Alloy	Polyamide (PA), Nylon	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
B15B-PASK(LF)(SN)	JST Sales America Inc.	CONN HEADER PA 15POS TOP 2MM TIN	Package: -	Stock8,676	-	PA	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	15	All	1	-	Through Hole	Kinked Pin, Solder	Locking Ramp	0.126" (3.20mm)	0.118" (3.00mm)	0.319" (8.10mm)	0.303" (7.70mm)	Square	Tin	-	Tin	Copper Alloy	Polybutylene Terephthalate (PBT), Glass Filled	-	-25°C ~ 85°C	-	UL94 V-0	Natural
BM18B-ZPDSS-TF(LF)(SN)	JST Sales America Inc.	CONN HEADER SMD 18POS ZPD	Package: -	Stock3,600	-	ZPD	Header	Outer Shroud Contact	0.059" (1.50mm)	Board to Cable/Wire	Shrouded - 4 Wall	18	All	2	-	Surface Mount	Solder	Locking Ramp	-	-	-	0.219" (5.56mm)	Rectangular	Tin	-	Tin	Copper Alloy	Polyamide (PA), Nylon	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
B3B-XH-A(LF)(SN)	JST Sales America Inc.	CONN HEADER XH TOP 3POS 2.5MM	Package: -	Stock337,302	-	XH	Header	Male Pin	0.098" (2.50mm)	Board to Cable/Wire	Shrouded - 4 Wall	3	All	1	-	Through Hole	Press-Fit, Solder	Detent Lock	-	0.134" (3.40mm)	-	0.276" (7.00mm)	Square	Tin	-	Tin	Brass	Polyamide (PA66), Nylon 6/6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
B10P-SHF-1AA(LF)(SN)	JST Sales America Inc.	CONN HEADER VERT 10POS NH	Package: -	Stock5,724	-	NH	Header	Male Pin	0.098" (2.50mm)	Board to Cable/Wire	Unshrouded	10	All	1	-	Through Hole	Solder	Friction Lock	0.236" (6.00mm)	0.134" (3.40mm)	0.496" (12.60mm)	0.126" (3.20mm)	Square	Tin	-	Tin	Brass	Polyamide (PA66), Nylon 6/6	-	-25°C ~ 85°C	-	UL94 V-0	Natural
B14B-PADSS-1(LF)(SN)	JST Sales America Inc.	CONN HEADER 14POS 2MM TIN	Package: -	Stock19,710	-	PAD	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	14	All	2	0.079" (2.00mm)	Through Hole	Solder	Locking Ramp	-	0.134" (3.40mm)	-	0.402" (10.20mm)	Square	Tin	-	Tin	Copper Alloy	Polyamide (PA66), Nylon 6/6, Glass Filled	Board Guide	-25°C ~ 85°C	-	UL94 V-0	Natural
B22B-PUDSS-1(LF)(SN)	JST Sales America Inc.	CONN HDR TOP 22 POS W/BOSS 2MM	Package: -	Stock55,950	-	PUD	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	22	All	2	0.079" (2.00mm)	Through Hole	Solder	Latch Holder	-	0.122" (3.10mm)	-	0.378" (9.60mm)	Square	Tin	-	Tin	Copper Alloy	Polyamide (PA66), Nylon 6/6, Glass Filled	Board Guide	-25°C ~ 85°C	-	UL94 V-0	Natural
B11B-PASK(LF)(SN)	JST Sales America Inc.	CONN HEADER PA 11POS TOP 2MM TIN	Package: -	Stock4,086	-	PA	Header	Male Pin	0.079" (2.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	11	All	1	-	Through Hole	Kinked Pin, Solder	Locking Ramp	0.126" (3.20mm)	0.118" (3.00mm)	0.319" (8.10mm)	0.303" (7.70mm)	Square	Tin	-	Tin	Copper Alloy	Polybutylene Terephthalate (PBT), Glass Filled	-	-25°C ~ 85°C	-	UL94 V-0	Natural
BM12B-SRSS-TB	JST Sales America Inc.	CONN HEADER SH 12POS TOP 1MM TIN	Package: -	Stock16,608	-	SR	Header	Male Pin	0.039" (1.00mm)	Board to Cable/Wire	Shrouded - 4 Wall	12	All	1	-	Surface Mount	Solder	Push-Pull	-	-	-	0.167" (4.25mm)	Square	Tin-Lead	-	Tin-Lead	Copper Alloy	Polyamide (PA), Nylon	Solder Retention	-25°C ~ 85°C	-	UL94 V-0	Natural
RX-H201TD-1190(LF)(SN)	JST Sales America Inc.	CONN HEADER VERT 20POS RX	Package: -	Stock7,668	-	RX	Header	Male Pin	0.100" (2.54mm)	Board to Cable/Wire	Shrouded - 4 Wall	20	All	2	0.100" (2.54mm)	Through Hole	Solder	Latch Lock/Eject Hooks, Long	-	0.110" (2.79mm)	-	0.689" (17.50mm)	Square	Tin	-	Tin	Brass	Polybutylene Terephthalate (PBT), Glass Filled	Keying Slot	-55°C ~ 85°C	-	UL94 V-0	Black

Rectangular Connectors - Headers, Male Pins
